Barracuda Backup 690
Easy Cloud-Connected Backup


Barracuda Backup 690

Barracuda Products
Barracuda Backup 690
Barracuda Backup Server Appliance 690
#BBS690a
List Price: $14,400.00
Our Price: $13,680.00

If you are currently working with another reseller you may not be eligible to receive any promotional items with your purchase. Please contact us before placing your order. BarraGuard.com reserves the right to deny free promotional items on any purchase.

Click here to jump to more pricing!

Click here for a Barracuda LIVE DEMO!Barracuda Backup Overview:

Barracuda Backup combines storage, software, and inline deduplication, to ensure your data is protected against loss no matter what happens. It’s easy to deploy, usually in less than an hour. There are no per-application or per-agent licensing fees, and its single-pane-of-glass admin console makes management fast and easy.

Available as a hardware or virtual appliance, Barracuda Backup delivers nearcontinuous data protection and replication to an off-site appliance or to the cloud


Ransomware protection—without paying the ransom.

Don't let criminals hold your data hostage. With Barracuda, recovering your data is as simple as eliminating the malware, deleting the criminally encrypted files, and restoring a good copy of your valuable data.

Recover data fast.

Get your systems restored and running quickly from physical appliances, virtual servers, offsite locations, or the cloud.

Protect hybrid physical, virtual, and SaaS environments.

Today's IT environments combine physical servers, virtual servers and public cloud data which all need full protection. Important data also resides in mail servers which may have limited retention policies. Barracuda protects your data no matter where it is located.


Protect Data Wherever It Resides

User error, malicious deletion, natural disasters, and cyber-attacks can all threaten your business. Barracuda protects data wherever it resides, including:

  • Files located on physical devices, virtual environments or the public cloud
  • Office 365 including SharePoint and OneDrive data
  • SQL data

Backed up data can be replicated to the offsite location of your choice, including to secure Barracuda cloud storage, another physical location, or AWS.

Recover Data Fast from Any Device

Backing up your data is only part of the story. Barracuda makes it simple to recover to a snapshot in time or just recover a set of affected files. We support physical and virtual restores, so you can recover data from anywhere.

If your primary storage is lost or no longer available, you can easily access your data stored in Barracuda Backup and even spin up a virtual machine in minutes with a complete set of your data. Barracuda LiveBoot provides fast and easy recovery for on-premises VMware environments. Cloud LiveBoot allows you to boot VMware and Hyper-V virtual machines (VMs) in the Barracuda Cloud for testing and file-based recovery.

Easy to Deploy—Even Easier to Manage

Simple and Flexible Deployment Options

Barracuda offers different physical and virtual options. Choose what works best for your environment:

  • Barracuda Backup Appliance. Purpose built backup physical appliance for onsite data protection.
  • Barracuda Cloud to Cloud. Backup your Microsoft Office 365 environment including emails, attachments, calendars, contacts and tasks as well as OneDrive and SharePoint Online and set your own retention policies.
  • Barracuda Virtual Backup. Get all the advantage of Barracuda backup on your own equipment.

Full Cloud-Based Management

Deployment, configuration, and ongoing management are all controlled via a centralized cloud-based console. You can manage the health of all backed up servers, network traffic utilization, detailed reports for your global network all from a single pane of glass.

Barracuda: Your Trusted Partner in Cyber-Security

When choosing a data protection solution, it pays to look beyond the hardware and software to the company that stands behind the product. Barracuda is the world's leading provider (in units shipped) of Purpose-Built Backup Appliances (PBBA) and is also a leading provider of cloud-based data protection. In fact, over 200,000 companies trust Barracuda to protect their data and networks.

Effective data protection requires more than just a good backup system, and Barracuda is more than just a data backup company. For even more protection, consider Barracuda Total Email Protection, the industry’s most complete email security platform We also offer a full line of email security, archiving, firewall, and content security products.

All products are supported by our award-winning 24x7 technical support staffed by in-house engineers with no phone trees.

Benefits:

Protecting your data has never been more crucial.

Today's complex infrastructures and targeted cyber-attacks require a complete backup strategy that protects data wherever it resides— on‑premises or in the cloud. Simple to configure and manage, Barracuda Backup is truly a "set it and forget it" solution for total peace of mind.

Defend against ransomware, disasters, and malicious destruction

Barracuda Backup lets you quickly recover files encrypted by ransomware. Simply eliminate the malware, delete the bad files, and restore them from a recent backup. Recovery can take as little as an hour—and the bad guys go home empty-handed.

Barracuda Backup’s hardened Linux OS is less vulnerable to threats than Windowsbased backup solutions. Data is protected in transit and at rest in the remote location by 256-bit AES encryption.

Rapid recovery from data loss

Barracuda Backup provides multiple recovery options to help you get back up and running quickly. With a Barracuda Cloud or Amazon Web Services (AWS) subscription, you can recover data from anywhere at any time, without the need for a local appliance.

Barracuda LiveBoot provides fast and easy recovery for on-premises VMware environments in cases where primary storage is lost or no longer available, while Cloud LiveBoot provides fast recovery for both VMware and Hyper-V virtual machines.

Flexible deploymentand recovery

Barracuda Backup is available as a hardware or as a virtual appliance. Models range in capacity from 1 terabyte to 160 terabytes, to accommodate your specific backup needs. Barracuda Backup also has a wide range of offsite replication options for disaster recovery (Barracuda Cloud, hardware or virtual appliance, AWS).


Features
Deployment Options Physical Appliance, Virtual Appliance
Offsite Replication Remote Physical Appliance, Remote Virtual Appliance, Barracuda Cloud Storage, Amazon Web Services (AWS)
Management Interface Barracuda Cloud Control Centralized Administration
Backup Agents Microsoft Windows (Windows Server, Hyper-V, Exchange, SQL), Linux, macOS
Network Backups Network Attached Storage (NAS)
Host-Level Virtual Environments VMware vSphere, Microsoft Hyper-V
Guest-Level Virtual Environments Citrix XenServer, Kernel-based Virtual Machine (KVM), Oracle VM, Red Hat Virtualization
Deduplication Global, Inline, Block-Level, Source- and Target-Based
Rapid Recovery LiveBoot, Cloud LiveBoot, Physical-to-Virtual (P2V), LiveBrowse
Long-Term Retention Offsite Vaulting to Barracuda Cloud, Export to Amazon Web Services (AWS), External Disk, Tape, Autoloader, Robotic Library

Features:

Backup

Replication
Barracuda Backup lets you protect against local disasters and data loss by using the cloud to simply and cost-effectively get data off-site. It lets you securely and efficiently replicate data to the Barracuda Cloud, a remote physical backup appliance, a remote virtual backup appliance, or Amazon Web Services (AWS) for off-site protection. 256-bit AES encryption of all data in transit and at rest ensures security.

Unlimited Barracuda Cloud Storage
Unlimited Barracuda Cloud Storage provides storage to replicate Barracuda Backup to the cloud. Unlimited Barracuda Cloud Storage subscriptions allow replication of data on Barracuda Backup, up to the capacity of your Backup product, to our geographically distributed enterprise-grade datacenters to store your data safely. The included offsite vaulting allows extended retention by moving multiple revisions off Barracuda Backup and into Barracuda Cloud.

Security
UBarracuda Backup includes support for 256-bit AES encryption of data at rest and in transit. This military-grade encryption provides organizations with non-disruptive encryption, protection from physical breach or theft, and the ability to meet the standards of some of the most common industry regulations.

Near Continuous Data Protection
The Barracuda Backup Agent can back up mission-critical servers every 15 minutes. These agents only look for new or changed files, minimizing the backup window required.

Inline Deduplication
Barracuda inline deduplication, an inherent capability of all Barracuda Backup products, lets organizations significantly reduce storage needs, bandwidth requirements, and backup costs. By deduplicating data as it is received, Barracuda Backup minimizes the time for completion of the full backup and replication process. Barracuda’s advanced variable block deduplication analyzes the data type and chunk size, setting a block size to obtain the greatest level of deduplication. For organizations protecting multiple sites, Barracuda’s global deduplication and cloud storage technology help distributed networks stay protected while reducing the backup storage footprint.

Offsite Vaulting
Organizations with conservative retention policies can use Offsite Vaulting to minimize the cost of backup storage. With Offsite Vaulting, organizations can move local copies of their monthly and yearly backups off their local appliance to the Barracuda Cloud or another Barracuda appliance.

Recovery

Data Recovery
Barracuda offers a wide range of restore options: Organizations with physical servers are able to perform bare metal restores in case of catastrophic failure, while virtual environments benefit from fast image-based restores. For customers with Instant Replacement: In the event of a complete site disaster, Barracuda will preload the most recent data and configuration settings stored in Barracuda Cloud Storage onto the replacement unit for emergency restores.

LiveBoot
Barracuda LiveBoot offers organizations protecting their VMware and Microsoft Hyper-V environments with Barracuda Backup the option to leverage Barracuda Cloud Storage if their own virtual environment goes down. Customers can have their local Barracuda Backup act as storage, booting the protected virtual machine from a deduplicated state within minutes. Customers that subscribe to Instant Replacement who replicate to Barracuda Cloud Storage can use Cloud LiveBoot to boot multiple VMs directly from deduplicated storage and assign private or public addresses to the devices.

Instant Replacement
In the event of a complete site disaster, Barracuda will preload the most recent data and configuration settings stored in Barracuda Cloud Storage onto a replacement unit for emergency restores. The replacement will be shipped the next business day after the preload is completed. Organizations can also leverage Cloud LiveBoot for offsite disaster recovery. As an added benefit, subscribers receive a free hardware refresh to the latest model every four years.

Management

Centralized Management
Barracuda’s robust central management allows organizations to manage multiple sites from a clean and simple-to-use interface. Administrators can define roles in their organization for access to each location.

Flexible Deployments
Barracuda Backup is available as both an all-in-one physical appliance or as software that can be deployed in virtual environments to leverage existing compute and storage infrastructures.

Model Comparison:

MODEL 190 295 290 390 490 690
CAPACITY
Usable Storage 1 TB 2 TB 2 TB 4 TB 8 TB 12 TB
Recommended Environment 500 GB 1 TB 1 TB 2 TB 4 TB 6 TB
SPECIFICATIONS
Form Factor Desktop Desktop 1U Micro 1U Mini 1U 1U
Dimensions
(inches: W x H x D)
9.1 x 1.7 x 6.0 10.0 x 2.0 x 8.3 16.8 x 1.7 x 10.2 16.8 x 1.7 x 14.0 16.8 x 1.7 x 19.8 17.2 x 1.7 x 27.0
Weight (lbs) 4 6 9 12 26 26
Network Interface 1Gb RJ45 1Gb RJ45 1Gb RJ45 1Gb RJ45 1Gb RJ45 2 x 10Gb RJ45
10Gb Fiber Interface
SFP+ Transceiver Module (LC Multi-Mode)
Disk Arrangement 1 x 1 TB SSD 1 x 2 TB SSD 1 x 2 TB SSD 2 x 4 TB SSD 4 x 4 TB SSD 4 x 10 TB SSD
Redundant Disk Array (Primary Array) SW RAID 1 SW RAID 10 SW RAID 10
Dedicated Database and OS Disks
Redundant Disk Array (Database/OS Array)
Swappable Disks Hot Swappable Hot Swappable
Redundant Power Supplies
Output Power (W) 60W 80W 250W 250W 400W 400W
AC Inputs (VAC) 100/240 100/240 100/240 100/240 100/240 100/240
Site-to-Site Replication Sender Sender Sender Sender Sender/Receiver Sender/Receiver
MODEL 790 890 895 990 995 1091 1191
CAPACITY
Usable Storage 18 TB 24 TB 36 TB 48 TB 80 TB 128 TB 168 TB
Recommended Environment 9 TB 12 TB 18 TB 24 TB 40 TB 50 TB 60 TB
SPECIFICATIONS
Form Factor 2U 3U 4U
Dimensions
(inches: W x H x D)
17.4 x 3.5 x 25.8 17.4 x 5.3 x 23.8 17.4 x 7.0 x 27.9
Weight (lbs) 52 52 70 76 114 121 121
Network Interface 2 x 10GB RJ45
10Gb Fiber Interface
SFP+ Transceiver Module (LC Multi-Mode)
Optional 2-port SFP+ Standard 2-port SFP+
Disk Arrangement 4 x 12 TB 6 x 12 TB 10 x 8 TB 12 x 10 TB 12 x 10 TB 18 x 12 TB 18 x 12 TB
Redundant Disk Array (Primary Array) HW RAID 10 HW RAID 60
Dedicated Database and OS Disks N/A 2 x 2 TB 4 x 2 TB 4 x 2 TB
Redundant Disk Array (OS) N/A HW RAID 1 HW RAID 10 HW RAID 10
Swappable Disks Hot Swappable
Redundant Power Supplies Hot Swappable
Output Power (W) 800W 1000W 1280W
AC Inputs (VAC) 100/240
Site-to-Site Replication Sender/Receiver

Technical Specs

Backup

  • Full local backup and restore
  • Inline, block-level, source- and target-based deduplication
  • Built-in WAN acceleration
  • Cloud or site-to-site replication
  • Real-time inline replication to offsite storage
  • Export to Amazon Web Services (AWS), external disk, tape, autoloaders, or robotic libraries
  • Near-continuous data protection
  • VMware Changed Block Tracking (CBT)
  • Encrypted client and server communication for additional security
  • In case of disaster, Instant Replacement can deliver a new unit preloaded with data and configuration backed up to Barracuda Cloud Storage

Offsite Vaulting

  • Vault historical revisions offsite to the Cloud
  • Storage or a remote location
  • Extend offsite-only retention up to 12 monthly and
  • 7 yearly revisions

Long-term Retention

  • Supports archiving to virtual tapes stored in AWS Simple Storage Service (S3) and Glacier using the AWS Storage Gateway-VTL

Ransomware Protection

  • Immutable backup protection
  • Hardened Linux platform
  • Multi-factor authentication (MFA)
  • Secure, air gapped cloud storage
  • Role-based access control
  • End-to-end encryption
  • Ability to create IP/network restrictions

Recovery

  • Physical-to-Virtual (P2V) restores
  • Bare metal restore for Windows
  • With a cloud subscription, download or recover data from anywhere at any time without the need for a local appliance
  • Rapid VM recovery with LiveBoot for VMware, and Cloud LiveBoot for VMware and Microsoft Hyper-V environments
  • Granular file recovery for VMware and Hyper-V
  • File revision history
  • Granular Microsoft Exchange message-level recovery
  • Customers replicating to AWS have the option to restore backed-up virtualized systems directly to their own AWS environment EC2 compute environment for recovery

Replication

  • 256-bit AES encryption of data in transit and at rest to remote locations
  • Barracuda’s replication technology gives you the flexibility to securely and efficiently send data to the Barracuda Cloud, a remote physical backup appliance, a remote virtual backup appliance, or AWS for offsite replication.
  • Because Barracuda manages and optimizes our infrastructure in AWS, setup and configuration of AWS replication is simple—no advanced understanding of AWS required.

Barracuda Backup FAQ:

What is the Barracuda Backup?

The Barracuda Backup is an affordable, integrated local and offsite data backup and disaster recovery solution. The Barracuda Backup combines an onsite appliance with a flexible monthly, quarterly or yearly subscription that replicates data offsite. Combining local and offsite storage provides the best of both worlds – onsite backups for the fastest restore times and secure, offsite storage for disaster recovery.

Why do I need a backup solution?

Equipment storing information can fail. Backup, whether it is local or offsite, maintains a redundant copy of an organization’s valuable data in the event of a system failure or natural disaster as well as retains data to fulfill compliance requirements and litigation requests. With the additional copy of data, IT administrators gain the ability to easily restore important files. A backup solution for data restores is an integral part of an organization’s disaster recovery plan.

Why can't I use tape or an external hard drive for backups? What are the benefits of a combined local and offsite backup solution?

Tapes require the manual management of scheduling backups. Hard drives only create one instance of your data. Whether using tapes or hard drives, the stored data has no means to minimize file duplications and does not possess revision history to select the correct historical version to revert back to. Another burden is the need to regularly transport data offsite for a secondary copy in the event of a system failure or disaster.

In comparison, an integrated local and offsite backup solution is easy to manage with automatic backups based on a set time, as well as the secure transfer of data offsite for disaster recovery.

Why should I use a dedicated appliance for my backups?

There are several advantages to using an appliance to conduct automated data backups and offsite replication. An appliance created for backup, like the Barracuda Backup Server, is a purpose-built appliance that enables centralized management of backup connections to multiple devices and provides the local storage necessary to keep a primary backup copy onsite for fast recovery in the majority of data loss scenarios.

SSoftware backup solutions need installation and management on every server they protect, plus requires the administration and support of additional hardware to provide recommended local storage of the backup data. Unlike many software solutions, the Barracuda Backup Server protects data using standard networking protocols from computers running a wide range of operating systems. Other benefits of using the appliance for backups include dedicated processing power for deduplication and compression to increase efficiency in storage and transmission, reduction of load on production servers by not having to run backup software and the creation of a dedicated restore device on your local network.

How is the Barracuda Backup different than other product offerings?

The Barracuda Backup creates a local copy of protected data and efficiently transfers the data offsite without additional burden to production servers. The offsite storage is monitored and managed by Barracuda Central as part of the monthly Barracuda Backup Subscription. With three secure copies of data and several different methods to restore an organization’s assets, the Barracuda Backup is a comprehensive, flexible and efficient solution to achieve your disaster recovery needs.

Is the Barracuda Backup safe?

The Barracuda Backup utilizes an aggressive combination of symmetrical and asymmetrical encryption. The United States government recently approved 192-bit AES encryption as the preferred method for protecting top secret information. The Barracuda Backup starts with the even more secure 256-bit AES encryption level. Your data is secured by this aggressive encryption methodology both while being transferred offsite and during its storage at Barracuda Central.

Where is my data stored with the Barracuda Backup?

The Barracuda Backup is an affordable, integrated local and offsite data backup and disaster recovery solution. The Barracuda Backup combines an onsite appliance with a flexible monthly, quarterly or yearly subscription that replicates data offsite. Combining local and offsite storage provides the best of both worlds – onsite backups for the fastest restore times and secure, offsite storage for disaster recovery.

What are the ways to restore data from Barracuda Backup?

Data is easy to restore using any of the following methods, including:

  1. Barracuda Backup Restore Browser
  2. Barracuda Backup local Restore Browser
  3. 24/7 Barracuda Technical Support restore assistance
  4. Shipment of restored data from Barracuda Networks

Can the Barracuda Backup help achieve compliance with common regulations?

Yes. Barracuda Backup addresses the security requirements necessary to support compliance with a wide range of industry-specific regulations such as HIPAA for the healthcare industry, and Gramm-Leach-Bliley for financial organizations.

Does Barracuda Backup help retain and produce data for litigation requests?

Yes. Retention policies using Barracuda Backup assists organizations in preparing for discovery requests by simplifying the retention and reproduction of electronic data. The flexible data retention options with the Barracuda Backup allow you to enforce specific policies for your various types of data.

Documentation:

Download the Barracuda Backup Datasheet (.PDF)

Pricing Notes:

Barracuda Products
Barracuda Backup 690
Barracuda Backup Server Appliance 690
#BBS690a
List Price: $14,400.00
Our Price: $13,680.00
Barracuda Backup 690 Cold Spare
Barracuda Backup Server Appliance 690 Cold Spare
#BBS690a-c
List Price: $10,080.00
Our Price: $9,576.00
Barracuda Energize Updates for 690
Energize Updates include Basic Support (Email 24x7, Phone 9am-5pm PST), Firmware Maintenance and Updates, Security Updates, and optional participation in the Barracuda Early Release Firmware program.
Barracuda Backup Server Appliance 690 Energize Updates Subscription 1 Year
#BBS690a-e
List Price: $2,760.00
Our Price: $2,622.00
Barracuda Instant Replacement
Instant Replacement includes next business day replacement hardware, Enhanced 24x7 Phone and Email Support, Data Migration and Data Recovery Services, Hard Disk Replacement and a Hardware Refresh every 4 years.
Barracuda Backup Server Appliance 690 Instant Replacement Subscription 1 Year
#BBS690a-h
List Price: $3,240.00
Our Price: $3,078.00
Barracuda Backup Subscriptions for 690
Barracuda Backup Subscriptions are optional and not required with the purchase of a new appliance. Subscriptions are purchased directly from Barracuda Networks when your appliance is registered. Barracuda Backup Subscriptions are $50.00 per month for 200GB of storage. For more information, please contact us.
Barracuda Backup Server Appliance 690 Unlimited Cloud Storage Subscription 1 Year
#BBS690a-b
List Price: $7,200.00
Our Price: $6,840.00
Barracuda Premium Support for 690
Please Note: Premium support on models 4X0 and below is available for customers who have purchased premium support on models 6X0 and above. Premium Support must be ordered WITH Instant Replacement for all hardware models. It may be purchased on virtual appliances without Instant Replacement purchase.
Barracuda Backup Server Appliance 690 Premium Support Subscription 1 Year
#BBS690a-p
List Price: $3,240.00
Our Price: $3,078.00
AWS Replication for Barracuda Backup Model 690
Barracuda Backup Server Appliance 690 Replication to AWS Subscription 1 Year
#BBS690a-xa
List Price: $3,000.00
Our Price: $2,850.00
Virtual Receiver Replication for Barracuda Backup Model 690
Barracuda Backup Server Appliance 690 Replication to a Virtual Receiver Subscription 1 Year
#BBS690a-x
List Price: $3,240.00
Our Price: $3,078.00

If you are currently working with another reseller you may not be eligible to receive any promotional items with your purchase. Please contact us before placing your order. BarraGuard.com reserves the right to deny free promotional items on any purchase.

email subscribe

Enjoy Exclusive Weekly Deals from Virtual Graffiti
